Why NAPTK Stabilizer Links, Sway Bar Link ?

An anti-roll bar (anti-sway bar, sway bar, stabilizer bar) is a part of many automobile suspensions that helps reduce the body roll of a vehicle during fast cornering or over road irregularities. It connects opposite (left/right) wheels together through short lever arms linked by a torsion spring.

An anti-sway or anti-roll bar is intended to force each side of the vehicle to lower, or rise, to similar heights, to reduce the sideways tilting (roll) of the vehicle on curves, sharp corners, or large bumps. With the bar removed, a vehicle's wheels can tilt away by much larger distances.

NAPTK sway bar is usually a torsion spring that resists body roll motions. It is usually constructed out of a cylindrical steel bar, formed into a "U" shape, that connects to the body at two points, and at the left and right sides of the suspension. If the left and right wheels move together, the bar rotates about its mounting points. If the wheels move relative to each other, the bar is subjected to torsion and forced to twist. Each end of the bar is connected to an end link through a flexible joint. The sway bar end link connects in turn to a spot near a wheel or axle, transferring forces from a heavily-loaded axle to the opposite side.

Forces are therefore transferred:

1.from the heavily-loaded axle

2.to the connected end link via a bushing

3.to the anti-sway (torsion) bar via a flexible joint

4.to the connected end link on the opposite side of the vehicle

5. to the opposite axle

For more information about NAPTK sway link，and  please download sway link catalogues here.

NAPTK STABILIZER LINK.pdf
